1. Two adjustable power levels, up to 3000mw, suitable for long-distance flight
2. 9 optional channels
3. Wide voltage input, supports 7-36V volts
4. With temperature control protection function to prevent high temperature burnout
5. Support 30.5x30.5mm (M3) installation holes
1.2G/1.3G-3W VTX has stronger impact resistance and better heat dissipation performance. 7-36V wide voltage input, with temperature control protection function to prevent overheating and burning. Supports 30.5x30.5mm (M3) installation holes.
Product name:1.2G/1.3G 3W VTX image transmission
Frequency band:1080MHz-1360MHz
Number of channels:
Rate: 1080/1120/1160/1200/1240/1280/1320/1360/1258 (MHz)
Output power:500mW/3000mW/Pit mode
Frequency stability: 100KHz (TyP.)
Antenna port impedance:50 0hms
Input voltage:DC7-36V (2-8S Battery)
Output voltage:5V@600mA
Antenna interface:MMCX
Cable interface:sh1.25 6pin
Video format:PAL/NTSC
Working temperature:-10 -+60
Due to different batches, there may be differences in product appearance, color, and printed text, which not affect the use.
Colour:Random Color(Color is random, no specification is accepted)
Material:PCB
Size:36x35x10mm
Installation hole:30.5x30.5mm (M3)
Package Contents:
1 x VTX Kit
Only the above package content, other products are not included.
Note: Light reflection and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
What's in the box
1 x VTX Kit
